NetMetal ac2
Our toughest long-range AP, now with dual-band support
More power and advanced features, with the same design philosophy as its predecessors – the new NetMetal ac² AP is sturdy, reliable, easy to use and extremely capable. This is the best way to add IPsec hardware acceleration to your backhaul link! We have added an out-of-the-box 2.4/5 GHz dual-concurrent (2.4GHz and 5GHz can be used at the same time) band support – no need for additional tinkering!
NetMetal ac² can handle massive loads, as it features an improved 4-core CPU and 256 MB RAM. There is a miniPCIe slot for an LTE or other wireless modules and an SFP port for fiber. The NetMetal ac² can be a very adaptable addition for all kinds of setups.
Two RP-SMA connectors allow adding an antenna of your choice. If necessary, you can adapt the NetMetal ac² for lower range use with such antennas as our HGO-antenna-OUT screw-on omni antenna unit (not included; available for ordering seperately)
The enclosure has an IP rating of IP66 with protection against splashing from any angle, but it can still be opened and closed with one hand. Very handy in rough environments!
Wireless specifications
| 2.4 GHz | Transmit (dBm) | Receive Sensitivity |
|---|---|---|
| 1MBit/s | 30 | -100 |
| 11MBit/s | 30 | -94 |
| 6MBit/s | 30 | -96 |
| 54MBit/s | 27 | -80 |
| MCS0 | 30 | -96 |
| MCS7 | 26 | -75 |
| 5 GHz | Transmit (dBm) | Receive Sensitivity |
|---|---|---|
| 6MBit/s | 30 | -96 |
| 54MBit/s | 27 | -80 |
| MCS0 | 30 | -96 |
| MCS7 | 26 | -75 |
| MCS9 | 23 | -72 |
- Produkta kods
- RBD23UGS-5HPacD2HnD-NM
- Arhitektūra
- ARM 32bit
- CPU
- IPQ-4019
- CPU kodolu skaits
- 4
- CPU nominālā frekvence
- 716 MHz
- Licences līmenis
- 4
- Operētājsistēma
- RouterOS
- Atmiņas apjoms (RAM)
- 256 MB
- Datu uzglabāšanas lielums
- 16 MB
- Datu uzglabāšanas veids
- FLASH
- Apkārtējās vides temperatūra testēšanas laikā
- -40°C to 70°C
- MTBF
- Approximately 200'000 hours at 25C
- PoE ieeja
- 802.3af/at
- PoE ieeja(V)
- 24-57 V
- DC ieeju skaits
- 2 (DC jack, PoE-IN)
- Maksimālais enerģijas patēriņš
- 28 W
- Ventilācijas veids
- Passive
- Wireless 2,4 GHz maks. datu pārraides ātrums
- 300 Mbit/s
- Wireless 2,4 GHz ķēžu skaits
- 2
- Wireless 2,4 GHz standarti
- 802.11b/g/n
- Wireless 2,4 GHz mikroshēmas modelis
- IPQ-4019
- Paaudzes Wireless 2,4 GHz
- Wi-Fi 4
- Wireless 5 GHz maks. datu pārraides ātrums
- 867 Mbit/s
- Wireless 5 GHz ķēžu skaits
- 2
- Wireless 5 GHz standarti
- 802.11a/n/ac
- Wireless 5 GHz mikroshēmas modelis
- IPQ-4019
- Paaudzes Wireless 5 GHz
- Wi-Fi 5
- 10/100/1000 Ethernet porti
- 1
- USB portu skaits
- 1
- USB Power Reset
- Yes
- USB savienotāja tips
- USB type A
- Maks. USB ierīces (A)
- 1
- PCB temperatūras kontrole
- Yes
- Sprieguma monitorings
- Yes
- Sertifikācija
- CE, FCC, IC, EAC, ROHS
